2N2222A (TO-92) package pinout. Note that parts that start with 'P2N' have a different pinout than those that start with '2N' and 'PN' (see text).
The 2N2222 is a common (BJT) used for general purpose low-power or switching applications. It is designed for low to medium, low, medium, and can operate at moderately high speeds. It was originally made in the metal can as shown in the picture. The 2N2222 is considered a very common transistor, and is used as an exemplar of an NPN transistor. It is frequently used as a small-signal transistor, and it remains a small general purpose transistor of enduring popularity. The 2N2222 was part of a family of devices described by at a 1962 convention.
Since then it has been made by many semiconductor companies, for example,. Contents. Specifications The registration of a device number ensures particular rated values will be met by all parts offered under that number. JEDEC registered parameters include outline dimensions, small-signal current, maximum values for voltage withstand, current rating, power dissipation and temperature rating, and others, measured under standard test conditions. Other part numbers will have different parameters. The exact specifications depend on the manufacturer, case type, and variation. Therefore, it is important to refer to the datasheet for the exact part number and manufacturer.
Jenis-jenis Ic Dan Fungsinya
Manufacturer V ce I c P D f T ST Microelectronics 2N2222A 40 V 800 mA 500 mW/1.8 W 300 MHz All variations have a or current gain (hFE) of at least 100 in optimal conditions. It is used in a variety of analog amplification and switching applications. Other NPN switching transistors NPN silicon transistors with similar properties are also made in a variety of small through-hole and surface mount packages including, and SOT-223. Replacements for the 2N2222 are commonly available now in the cheaper packaging, where it is known as the PN2222 or P2N2222, which has similar specifications except for the lower maximum collector current. The P2N2222 has a different order of pins than the metal case 2N2222, with its emitter and collector connections switched; other plastic-case transistors also have different pinouts.
Ic Dan
Single transistors are also available in several different surface mount packages, and a number of manufacturers market surface mount packages that incorporate several 2N2222-type transistors in one package as an array of transistors. The general specifications of the various variants are similar, with the biggest difference being the maximum allowable current and power dissipation. The is a low voltage, low current, general-purpose switching transistor in a TO-92 package. The is an equally popular transistor complementary to the 2N2222. The is an NPN transistor that can only switch one-third the current of the 2N2222 but has otherwise similar characteristics.
The 2N3904 exhibits its forward gain (beta) peak at a lower current than the 2N2222, and is useful in amplifier applications with reduced Ic, e.g., (gain peak at 10 mA for the 2N3904 but 150 mA for the 2N2222). The 2N2219 is very similar with higher power dissipation rating. Part numbers The 2N2222 (NPN) and (PNP) are complementary transistor pairs. Transistor part numbers Thru-hole NPN 2N2222 MMBT2222 PZT2222A PNP MMBT2907 PZT2907A See also. References.
